| Type | Liquid-cooled, 12 valve, DOHC, inline 3-cylinder |
|---|---|
| Capacity | 1160 cc |
| Bore | 90.0 |
| Stroke | 60.8 |
| Compression | 13.2:1 |
| Max Power EC | 180 PS to 177 HP |
| Max Torque EC | 125nm to 92 LB FT |
| System | Multipoint sequential electronic fuel injection with electronic throttle control |
| Exhaust | Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer |
| Final Drive | X-ring chain |
| Clutch | Wet, multi-plate, slip |
| Gearbox | 6 speed |
| Frame | Aluminum twin spar frame, bolt-on aluminum rear subframe |
|---|---|
| Swingarm | Aluminum, single-sided |
| Front Wheel | Cast aluminum, 17 x 3.5 in |
| Rear Wheel | Cast aluminum, 17 x 6.0 in |
| Front Tire | 120/70 ZR 17 (58W) |
| Rear Tire | 190/55 ZR 17 (75W) |
| Front Suspension | Öhlins 43mm fully adjustable USD forks, 120mm travel. Öhlins S-EC 2.0 OBTi system electronic compression / rebound damping |
| Rear Suspension | Öhlins monoshock RSU with linkage, 120mm rear wheel travel. Öhlins S-EC 2.0 OBTi system electronic compression / rebound damping |
| Front Brakes | Twin 320mm floating discs. Brembo Stylema monobloc calipers, OC-ABS, radial master cylinder with separate reservoir, span |
| Rear Brakes | Single 220mm disc. Brembo twin piston caliper, OC-ABS. Rear master cylinder with separate reservoir |
| Instrument Display and Functions | Full-colour 5" TFT instruments |
| Width Handlebars | 29.84 in (758 mm) |
|---|---|
| Height Without Mirror | 44.1 in (1120 mm) |
| Seat Height | 32.68 in (830 mm) |
| Wheelbase | 56.65 in (1439 mm) |
| Rake | 23.9 º |
| Trail | 4.12 in (104.7 mm) |
| Tank Capacity | 4.1 US gal (15.5 litres) |
| Wet Weight | 438 Lbs |
| Type | Liquid-cooled, 12 valve, DOHC, inline 3-cylinder |
|---|---|
| Capacity | 1160 cc |
| Bore | 90.0 |
| Stroke | 60.8 |
| Compression | 13.2:1 |
| Max Power EC | 180 PS to 177 HP |
| Max Torque EC | 125nm to 92 LB FT |
| System | Multipoint sequential electronic fuel injection with electronic throttle control |
| Exhaust | Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer |
| Final Drive | X-ring chain |
| Clutch | Wet, multi-plate, slip |
| Gearbox | 6 speed |
